Technical specifications
General
Receiver Type L1, C / A code, 1.575 GHz Frequency / L2 C / A code, 1.602 GHz Frequency
Channels 32 channels
Position Update Rate Up to 10 Hz (1,5,10)
Horizontal Accuracy 3 m (9.8 ft)
Heading Accuracy +/- 3 °
Rate of Turn +/- 3 °
Pitch / Roll Accuracy @ 30 degrees 1 grade error
Cold Start 50 sec
Start-Up Time 3 sec
Satellite Reacquisition 5 sec
Environmental
Operating Temperature -25 ° C to + 60 ° C
Storage Temperature -40 ° C to + 85 ° C
Splash Proof IPX7
Humidity 40 ° C, 93% RH, operating
Electrical
Input Voltage 9 V DC - 18 V DC
Reverse Polarity Protection Yes
Power Consumption Current Consumption <100 mA @ 12 V DC
Dimensions 90 mm (diam) x 38mm (height) 3.54 "(diam) x 1.50" (height)
Weight 0.14 Kg (0.3 lbs) aprox
Power / Data Cable NMEA 2000 thru NMEA 2000 network
Antenna Connector NMEA 2000 Micro C: Lowrance attached cable with Micro-C connector
Mounting Flush mount / Standard Pole Mount
Communications
NMEA 2000 Data I / O Protocol
NMEA 2000 PGNs
PGN Number PGN Title: 126992 System Time, 129025 Position, Rapid Update, 129026 COG & SOG RU, 129029 Position Data, 129539 GNS DOP, 129540 GNS Satellites in view, 127258 Magnetic Variation, 127250 Compass Heading (Vessel Heading), 127251 Rate of Turn, 127257 Attitude
