Furuno B285M Transducer
BRONZE THROUGH Chirp 1KW with Fairing block
The B285M's midrange frequency offers the right combination of under-vessel coverage, extended depth range, and the ability to produce clean, accurate target and structure returns in medium to deep water. The medium frequency also provides excellent shallow to medium depth performance, bottom detail and fish target separation. Operating at a frequency range of 85 to 135 kHz, this transducer detects fish at medium depths up to 457 m (1500') and provides ultra-sharp target resolution.
This model is also ideal for single channel sonar applications where operating in Chirp mode gives you a greater opportunity to see what's in the water column. Simply create presets for 85 and 135 kHz and alternate between wide and narrow beams to scan an area and then locate structure.
The included high-performance fairing improves broadband performance at speeds above 30 knots.
CHARACTERISTICS
Fast response depth and water temperature sensing
1 kW of power with a maximum depth of 457 m (1500')
Average frequency: 85 to 135 kHz
Beam width 16° to 11°
50 kHz total bandwidth
It covers the most popular fishing frequencies of 88 and 107 kHz plus everything else in the bandwidth
Bronze housing for use on fiberglass or wooden hulls
Recommended for planing or displacement hulls
High performance fairing for optimal performance at higher speeds
Also available with transom mount (TM185M)
Patented Xducer I technology
