Garmin Display GNX 21 4 "b / w
Large, easy-to-read black digits and graphics on a white background provide high contrast and excellent visibility.
Backlight with 7 different customizable colors
Glass-bonded LCD and anti-glare display
Fully customizable user profiles to view the most important data
Low power consumption (25mA) with 350mW (no backlight) / 400mW (medium level backlight)
GNX 21 4 ”monochrome display superimposes white digits on a black background, with high contrast for clear visibility in any light condition and any reading angle. The GNX 21 is the first glass-bonded LCD display with three different data fields and thanks to the fully customizable profiles, it is possible to view and customize the layout of over 50 data pages. The Auto-scroll function, on the other hand, allows you to view only the data of interest in rotation.
If a different color is desired, the display can be customized by choosing from 7 different colors: red, orange, yellow, green, blue or purple. On the basis of these colors the user can also create a custom one for an optimal visualization of the data.
Specifications Appearance and performance
Physical dimensions 110 x 115 x 30 mm (4.33 "x 4.53" x 1.18 ")
Weight 230 g (8 oz)
Screen size, WxH 4 "diagonal
Screen type Inverted LCD, monochrome
IPX7 waterproof rating
Glass screen Yes
Operating temperature 9-16 V (from NMEA 2000)
Compass Safe Distance 209 mm (8.25 in.)
Operating voltage 9-16 V (from NMEA 2000)
Energy consumption
0.35W (day); 0.4 W (night)
Flat or Flush mounting options
Features and benefits
NMEA 2000® certified Yes
NMEA 0183 compatible Yes
Automatic activation Yes
User profiles Yes
Packaging GNX display
Protective cover
2m NMEA 2000 cable
T connector
Installation kit
User Manual
