TECHNICAL FEATURES
General
COLOR White or Black
USE Fresh water, brackish water and salt water
IPX7 WATERPROOF RATING
INSTALLATION POSITION Bow
MOUNTING STYLE Swivel mount
MAXIMUM DISPLACEMENT 100 lbs per ISO 13342 with 36V high efficiency propeller or 80 lbs per ISO 13342 with 24V DC high efficiency propeller
INTEGRATED COMPASS SENSOR
BUILT-IN GPS Yes (Dual Frequency GPS)
3 year WARRANTY
REMOTE CONTROL INCLUDED Yes (included)
COMPATIBLE WITH FOOT CONTROLS
BATTERY INDICATOR
SPEED CONTROL Yes (20 steps)
DIRECTION INDICATOR LIGHT
BRIDGE STABILIZER Yes (90" only)
Electrical characteristics
VOLTAGE 24V/36V.
ELECTRIC GUIDE
Fishfinder Features and Specifications
GT56UHD-TR TRANSDUCER included in Black versions only
LIVESCOPE CABLE INTEGRATION Yes (LiveScope transducer and Kraken mounting bracket required)
QUATIX REMOTE CONTROL SUPPORTED
Autopilot functions
COMPLETION OF THE ROUTE
MOORING POINT
MAINTAINING DIRECTION
CRUISE CONTROL
GESTURE FUNCTIONS Yes (manual+, direction hold+, slow forward+)
Remote Control Features
SCREEN SIZE 1.2″ (30.4 mm) diameter
SCREEN RESOLUTION 240 x 240 pixels
DISPLAY TYPE Color, anti-glare, transflective MIP (Memory-In-Pixel)
PROGRAMMABLE CHARTPLOTTER KEYS
CHECKING AUTOPILOT FUNCTIONS
IPX7 WATERPROOF RATING
BATTERY LIFE Typical usage with backlight at minimum, 43.2 weeks
FLOATS
